Dryer Section

Lubricant selection for dryer section in paper manufacturing.

Mobil

Dryer bearing circulation system
SHC PM / DTE PM

Grease-lubricated dryer bearings
Mobilith SHC PM / SHC Polyrex

Separate drive gearbox
SHC 600 / Mobilgear SHC XMP / Mobilgear 600 XP

Electric motor bearings
Polyrex EM

Grease-lubricated couplings
Mobilgrease XTC / Mobilux EP 111 / Mobilith SHC 1500, as specified

Shell

Dryer bearing circulation system
Paper Machine S3 M / S2 M; Morlina S4 B where approved

Grease-lubricated dryer bearings
Gadus high-temperature grade: application selection required

Separate drive gearbox
Omala synthetic gear-oil family

Electric motor bearings
Gadus S5 V100 2

Grease-lubricated couplings
Dedicated OEM-approved coupling grease: selection required

TotalEnergies

Dryer bearing circulation system
MISOLA range, matched to wet- or dry-end duty

Grease-lubricated dryer bearings
CERAN high-temperature bearing grade: selection required

Separate drive gearbox
CARTER SH

Electric motor bearings
ALTIS EM 2

Grease-lubricated couplings
Dedicated OEM-approved coupling grease: selection required

Caltex

Dryer bearing circulation system
Clarity Machine Oil — confirm UAE supply and OEM approval

Grease-lubricated dryer bearings
High-temperature paper-machine bearing grease: regional selection required

Separate drive gearbox
Meropa EliteSyn WL

Electric motor bearings
Black Pearl SRI 2

Grease-lubricated couplings
Dedicated OEM-approved coupling grease: selection required

Selection notes

Steam-heated cylinders impose high oil temperatures. Match viscosity, oxidation resistance, water separation and flow to the OEM specification. Mobil also lists Paper Machine Oil S 220 for specified duty; 220 is not a universal viscosity recommendation.

Product families for technical selection, not a direct interchange chart. Confirm the exact grade, current UAE product data sheet, OEM approval and lubricant compatibility before use.
